Wire front-end automatic processor
1. This machine adopts pneumatic design, each station can be operated independently, or multiple stations can be
completed at one time. The chuck can be automatically opened and closed; The chuck adopts the exposed mechanism to
make the wire easier to place;
2.Applicable wire: 1185 series, USB series, audio series, outer cotton braid series, machine line, machine line, medical
equipment line, HD data line series.
| Name | Wire front-end automatic processor |
|
Model
|
F01
|
|
Features
|
Heat stripping outside braid, to skin, twist line, aluminum foil one
|
|
Peeling range
|
OD:2.0-5.5mm
|
|
Heating mode
|
Intelligent temperature control + heating tube
|
|
Working length
|
L:8-50mm
|
|
Operation efficiency
|
1500-1800PCS/H
|
|
Applicable material
|
PVC TPU TPE
|
|
power supply
|
AC220V 50HZ DC:24V
|
|
Air pressure
|
Air:0.4-0.8mpa
|
|
Dimensions
|
1300*700*1400MM
|
|
Weight
|
208KG±20KG
|
